5962R1523601VXA
品牌
供应商
分类
放大器>>运算放大器>>低噪声运算放大器(≤ 10nV/√Hz)
描述
航空航天四路低噪声轨到轨 I/O 低功耗运算放大器
物料参数
| Product Lifecycle: | 推荐用于新设计 |
| Package: | 14-Lead Flatpak (Metal Sealed Bottom Braised Hermetic) |
| # of Amps: | 4 |
| Vos (max): | 100µV |
| Ibias (max): | 250nA |
| Ios (max): | 25nA |
| Rail to Rail: | Both |
| Iq/Amp (max): | 700µA |
| Vs span (min): | 3V |
| Vs span (max): | 30V |
| CMRR (min): | 98dB |
| Input Architecture: | Bipolar |
| PSRR DC (min): | 110dB |
| Out V+ Headroom (max): | 100mV |
| Out V- Headroom (max): | 100mV |
| Min Stable Gain: | 1V/V |
| Shutdown: | No |
| Over-the-Top: | No |
| Feedback Type: | Voltage |
| Package Area: | 65.41923mm² (14-Lead Flatpak (Metal Sealed Bottom Braised Hermetic)) (5962L1523602VXA)mm² |
| Export Classification: | EAR99 |
| Automotive: | No |
| Reliability Level: | Class S |
| Temp Range: | -55 to 125°C |
| Package Finish Code: | PB |
| Package Height: | 2.92mm (14-Lead Flatpak (Metal Sealed Bottom Braised Hermetic)) (5962L1523602VXA)mm |
| Launch Date: | 2018-01-04 |
| Terminal Finish: | PB |
| Temp Range Code: | NA |
| EP: | No |
| Design Tools: | LTspice |
