TLE42994GM
品牌
供应商
分类
Power>>Linear Voltage Regulator (LDO)>>Linear voltage regulators
描述
The TLE42994G is especially designed for automotive applications that need to be in ON state during the car’s engine is turned off.
物料参数
| Operating Temperature max: | 150.0°C |
| Dropout Voltage: | 220.0mV |
| Accuracy: | 2.0% |
| Quiescent Current: | 65.0µA |
| Operating Voltage max: | 45.0V |
| Power Good: | no |
| Watchdog: | no |
| Over Voltage Protection: | no |
| Early Warning: | yes |
| Status Output: | no |
| Qualification: | Automotive |
| Power Fail: | no |
| Enable (=Inhibit): | yes |
| Reset: | yes |
| Output Voltage Type: | 5.0 V |
| Hold: | no |
| Output Current max: | 150.0mA |
| Regulator Type: | General Purpose |
| Budgetary Price €/1k: | 0.75 |
| Budgetary Price €/1k: | 0.75 |
| Family: | OPTIREG™ linear General Purpose |
| Currently Planned availability until at least: | 2038 |
